Grove Gear B Series Flexaline/Ironman - Single Reduction Right Angle

Grove Gear's "B" series of right-angle gearboxes are designed for efficient power transmission and low maintenance.

The center distance options range from 1.33" to 3.25" and the reduction ratios range from 5:1 to 100:1. These options provide versatility and customization for various industrial applications.

Model B813

Center Distance: 1.33"
Reduction Ratios (X:1): 5, 7.5, 10, 15, 20, 25, 30, 40, 50, 60, 80, 100
Output Positions (Assemblies): L, R, D
Hollow Bore Diameters (inches): N/A
Output Shaft Diameters (inches): .625
NEMA Frames Sizes: N/A

Model B815

Center Distance: 1.54"
Reduction Ratios (X:1): 5, 7.5, 10, 15, 20, 25, 30, 40, 50, 60, 80, 100
Output Positions (Assemblies): L, R, D
Hollow Bore Diameters (inches): N/A
Output Shaft Diameters (inches): .750
NEMA Frames Sizes: N/A

Model B818

Center Distance: 1.75"
Reduction Ratios (X:1): 5, 7.5, 10, 15, 20, 25, 30, 40, 50, 60, 80, 100
Output Positions (Assemblies): L, R, D
Hollow Bore Diameters (inches): N/A
Output Shaft Diameters (inches): .875
NEMA Frames Sizes: N/A

Model B821

Center Distance: 2.06"
Reduction Ratios (X:1): 5, 7.5, 10, 15, 20, 25, 30, 40, 50, 60, 80, 100
Output Positions (Assemblies): L, R, D
Hollow Bore Diameters (inches): N/A
Output Shaft Diameters (inches): 1.00
NEMA Frames Sizes: N/A

Model B824

Center Distance: 2.38"
Reduction Ratios (X:1): 5, 7.5, 10, 15, 20, 25, 30, 40, 50, 60, 80, 100
Output Positions (Assemblies): L, R, D
Hollow Bore Diameters (inches): N/A
Output Shaft Diameters (inches): 1.125
NEMA Frames Sizes: N/A

Model B826

Center Distance: 2.63"
Reduction Ratios (X:1): 5, 7.5, 10, 15, 20, 25, 30, 40, 50, 60, 80, 100
Output Positions (Assemblies): L, R, D
Hollow Bore Diameters (inches): N/A
Output Shaft Diameters (inches): 1.125, 1.25
NEMA Frames Sizes: N/A

Model B830

Center Distance: 3.00"
Reduction Ratios (X:1): 5, 7.5, 10, 15, 20, 25, 30, 40, 50, 60, 80, 100
Output Positions (Assemblies): L, R, D
Hollow Bore Diameters (inches): N/A
Output Shaft Diameters (inches): 1.25
NEMA Frames Sizes: N/A

Model B832

Center Distance: 3.25"
Reduction Ratios (X:1): 5, 7.5, 10, 15, 20, 25, 30, 40, 50, 60, 80, 100
Output Positions (Assemblies): L, R, D
Hollow Bore Diameters (inches): N/A
Output Shaft Diameters (inches): 1.375, 1.5
NEMA Frames Sizes: N/A

Model B842

Center Distance: 4.25"
Reduction Ratios (X:1): 5, 7.5, 10, 15, 20, 25, 30, 40, 50, 60, 80, 100
Output Positions (Assemblies): L, R, D
Hollow Bore Diameters (inches): N/A
Output Shaft Diameters (inches): 1.875
NEMA Frames Sizes: N/A

Model B852

Center Distance: 5.25"
Reduction Ratios (X:1): 5, 7.5, 10, 15, 20, 25, 30, 40, 50, 60, 80, 100
Output Positions (Assemblies): L, R, D
Hollow Bore Diameters (inches): N/A
Output Shaft Diameters (inches): 2.00
NEMA Frames Sizes: N/A

Model B860

Center Distance: 6.00"
Reduction Ratios (X:1): 5, 7.5, 10, 15, 20, 25, 30, 40, 50, 60, 80, 100
Output Positions (Assemblies): L, R, D
Hollow Bore Diameters (inches): N/A
Output Shaft Diameters (inches): 2.50
NEMA Frames Sizes: N/A

Model B870

Center Distance: 7.00"
Reduction Ratios (X:1): 5, 7.5, 10, 15, 20, 25, 30, 40, 50, 60, 70
Output Positions (Assemblies): L, R, D
Hollow Bore Diameters (inches): N/A
Output Shaft Diameters (inches): 2.75
NEMA Frames Sizes: N/A

Model B880

Center Distance: 8.00"
Reduction Ratios (X:1): 5, 7.5, 10, 15, 20, 25, 30, 40, 50, 60, 70
Output Positions (Assemblies): L, R, D
Hollow Bore Diameters (inches): N/A
Output Shaft Diameters (inches): 3.00
NEMA Frames Sizes: N/A

Model B8100

Center Distance: 10.00"
Reduction Ratios (X:1): 5, 7.5, 10, 15, 20, 25, 30, 40, 50, 60, 70
Output Positions (Assemblies): L, R, D
Hollow Bore Diameters (inches): N/A
Output Shaft Diameters (inches): 3.75
NEMA Frames Sizes: N/A
