Electric motors for nearly every application, need and operating environment. Manufacturing electric motors since 1949.

Tatung Super-Max TEFC

Tatung Rolled Steel NEMA 56 Frame

Tatung Stainless TEFC

Output:     1HP ~ 500HP

Poles:     2, 4 & 6P

Frame Size:     140T ~ N5808

Frequency:     60 Hz

Enclosure:     TEFC

Efficiency:     NEMA Premium

Power:     3-Phase

Standard Voltage:     200-230/460V & 575V (200HP and above are 460 or 575V only)

Service Factor:     1.15

Electrical Design:     B

Insulation Class:     F

Temp Rise:     B Rise @ 1.0S.F

Frame Material:     Cast iron

Output:     1/3HP ~ 2HP

Poles:     2, 4 & 6P

Frame Size:     56 or 56C

Frequency:     60 Hz

Enclosure:     TEFC

Efficiency:     NEMA Premium (1HP & above)

Power:     3-Phase

Standard Voltage:     200-230/460V

Service Factor:     1.15

Electrical Design:     B

Insulation Class:     F

Temp Rise:     B Rise @ 1.15S.F

Frame Material:     Rolled Steel

Output:     1/4HP ~ 10HP

Poles:     2, 4 & 6P

Frame Size:     56~256T and 56C~256TC

Frequency:     60 Hz

Enclosure:     TEFC,TENV

Efficiency:     NEMA Premium (1HP & above)

Power:     3-Phase

Standard Voltage:     200-230/460V & 575V

Service Factor:     1.15

Electrical Design:     B

Insulation Class:     F

Temp Rise:     B Rise @ 1.0S.F

Frame Material:     Stainless Steel
